FI-20N-FOAM – Portable Foam Application Unit (20 Gallon / 75.7 L)
The FI-20N-FOAM is a professional portable foam application unit featuring a 20-gallon (75.7-liter) tank, designed for the application of cleaning and sanitizing chemicals in foam form. Powered by compressed air and utilizing a pre-mixed chemical solution, the unit produces thick, long-lasting foam that adheres effectively to both horizontal and vertical surfaces, improving cleaning efficiency and chemical contact time.
The FI-20N-FOAM is ideal for food processing plants, agricultural facilities, vehicle and equipment washing, industrial cleaning operations, and sanitation programs where larger solution capacity and extended operating time are required.
The unit is equipped with a transparent tank for easy monitoring of solution levels, a front-facing drain valve for quick and convenient emptying, and an integrated hose management system. Anti-kink hose protection helps prevent hose damage and flow restrictions, while the built-in in-line strainer protects the pump from debris and contaminants, extending equipment life and reducing maintenance costs.
Designed for easy servicing, the FI-20N-FOAM features a modular construction with a hinged back plate and a quick-change pump system, allowing fast access to internal components and minimizing downtime. The unit can also be customized with various seal materials and color-coded components to meet specific operational and hygiene requirements.
Key Features
- Powered by compressed air
- Uses a pre-mixed chemical solution (Pre-Mix system)
- Large 20-gallon (75.7 L) tank capacity
- Transparent tank for easy solution level monitoring
- Front-facing drain valve for convenient emptying
- Anti-kink hose protection
- Built-in in-line strainer for pump protection
- Integrated hose holder
- Modular design for easy maintenance
- Quick-change pump system
- Customizable configurations for chemical compatibility and process identification
- Suitable for professional cleaning, foaming, washing, and sanitizing applications
Technical Specifications
| Parameter |
Value |
| Model |
FI-20N-FOAM |
| Tank Capacity |
20 Gallons (75.7 L) |
| Operating Principle |
Pre-Mixed Solution |
| Power Source |
Compressed Air |
| Recommended Operating Pressure |
40–80 PSI (2.8–5.5 Bar) |
| Maximum Operating Pressure |
100 PSI (6.9 Bar) |
| Air Consumption |
5–10 CFM |
| Hose Length |
20 ft (6 m) |
| Foam Output |
15–30 gal/min (57–114 L/min) |
| Solution Flow Rate |
Approximately 2–2.3 gal/min (7.6–8.7 L/min) |
| Tank Material |
Chemical-resistant polyethylene |
| Mobility |
Heavy-duty wheels and handle |
| Configuration |
Portable Pre-Mix Foam System |
Standard Equipment
- 20-gallon (75.7 L) tank mounted on wheels
- 20 ft (6 m) reinforced hose
- Stainless steel foam wand
- On/off ball valve
- Integrated hose holder
- Quick-change pump
- Built-in in-line strainer
- Anti-kink hose protection
- Operator’s manual
Typical Applications
- Food processing facilities
- Dairy and beverage plants
- Meat and poultry processing operations
- Farms and livestock facilities
- Vehicle and fleet washing
- Industrial equipment cleaning
- Production area sanitation
- Warehouses and logistics facilities
- Cleaning and disinfection programs
- HACCP-controlled environments
Customization Options
- Pump seal materials for chemical compatibility:
- Santoprene (standard)
- Viton
- Kalrez
- Color-coded lids and hoses
- Foam wand options:
- Zero-degree spray tip
- Fan spray tip
- Optional air-line moisture separator
The FI-20N-FOAM Portable Foam Application Unit is designed for demanding cleaning and sanitation applications requiring increased solution capacity, reliable foam generation, and extended operating time. Its durable construction, ease of maintenance, and customization options make it an excellent choice for professional users in industrial and food-processing environments.
